| Cooling only models | | ARC 017 A | ARC 022 A | ARC 032 A | ARC 040 A |
| Net cooling capacities | kW | 17.2 | 22 | 30 | 40 |
| Power input | kW | 5.5 | 7.3 | 9.5 | 13.7 |
| EER | | 3.1 | 3.0 | 3.1 | 2.9 |
| Working range (full load / partial load) | °C | | 7°C ~ 46°C / | -10°C ~ 52°C | |
| Heat pump models | | ARH 017 A | ARH 022 A | | ARH 032 A | ARH 040 A |
| Net cooling capacities | kW | 17 | 21.5 | | 30 | 39 |
| Power input in cooling | kW | 5.8 | 7.6 | | 9.8 | 13.9 |
| EER | | 2.9 | 2.8 | | 3.0 | 2.8 |
| Heating capacities (1) | kW | 16.6 | 20.6 | | 28.6 | 37.8 |
| Power input in heating | kW | 5.3 | 6.7 | | 9.6 | 12.7 |
| COP | | 3.1 | 3.0 | | 3.0 | 3.0 |
| Working range (full load / partial load) | °C | | -10°C ~ 46°C | / -10°C ~ 52°C | |
| Cooling only + Gas heating models | | ARG 017 A | ARG 022 A | | ARG 032 A | ARG 040 A |
| Net cooling capacities | kW | 17.2 | 22 | | 30 | 40 |
| Cooling power input | kW | 5.5 | 7.3 | | 9.5 | 13.7 |
| Standard Heating capacities (1) NET | kW | 23 | 23 | | 23 | 23 |
| Natural gas 2ND-H, G20 | m3/h | 2.6 | 2.6 | | 2.6 | 2.6 |
| High Heating capacities (1) NET | kW | – | – | | 40 | 40 |
| Natural gas 2ND-H, G20 | m3/h | – | – | | 4.5 | 4.5 |
| Working range (full load / partial load) | °C | | -15°C ~ 46°C | / -15°C ~ 52°C | |
| Heat pump + Gas heating models | | ARD 017 A | | ARD 022 A | | ARD 032 A | ARD 040 A |
| Net cooling capacities | kW | 17.2 | | 21.5 | | 30 | 39 |
| Power input in cooling | kW | 5.5 | | 7.6 | | 9.8 | 13.9 |
| Heating capacities (1) | kW | 16.6 | | 20.6 | | 28.6 | 37.8 |
| Power input in heating | kW | 5.3 | | 6.7 | | 9.6 | 12.7 |
| Standard Heating capacities (1) NET | kW | 23 | | 23 | | 23 | 23 |
| Natural gas 2ND-H, G20 | m3/h | 2.6 | | 2.6 | | 2.6 | 2.6 |
| High Heating capacities (1) NET | kW | – | | – | | 40 | 40 |
| Natural gas 2ND-H, G20 | m3/h | – | | – | | 4.5 | 4.5 |
| Working range (full load / partial load) | °C | | | -15°C ~ 46°C | / -15°C ~ 52°C | |
| Common characteristics | | | | | | | |
| Power supply | | | | | | 400V/3 + N/ 50Hz | |
| Main switch | | | | A | 20 | | 25 | | 40 | 50 |
| Main cable | | | | Nbr. x mm2 | 5 x 4 | | 5 x 6 | | 5 x 10 | 5 x 16 |
| Cable to thermostat | Nbr. x mm2 | | | 10 x 0,22 | |
| Number of circuits / Compressor type | | 1 / Scroll | | | 1 (Tandem) / Scroll |
| Evaporator fan | Airflow | m3/h | 3400 | | 4300 | | 5700 | 7400 |
| at nominal airflow | | Power input | kW | 1 | | 1.7 | | 2.9 | 2.9 |
| | | Height | mm | 1 420 | | 1 420 | | 1 420 | 1 420 |
| Nett dimensions | | Length | mm | 1 866 | | 1 866 | | 2 135 | 2 135 |
| | | | Depth | mm | 1 540 | | 1 540 | | 1 850 | 1 850 |
| Nett weight | ARC / ARG | kg | 420 / 455 | | 440 / 465 | | 576 / 616 | 580 / 620 |
| Nett weight | ARH / ARD | kg | 425 / 460 | | 445 / 470 | | 582 / 622 | 586 / 626 |
| | | | | | | | | | | | | | |
